产品详情与编号
序号 产品编号 名称 Packaging unit Thread - M Clamping range - D 售价 订购数量
  全部
全部
全部
全部
全部

1.0 372051 Pipe ring stainless MP-MRI 125 M12 Packaging unit 5 pc Thread - M M12 Clamping range - D 122 - 127 mm ¥455.00
2.0 372055 Pipe ring stainless MP-MRI 6" M16 Packaging unit 10 pc Thread - M M16 Clamping range - D 162 - 168 mm ¥230.00
3.0 372049 Pipe ring stainless MP-MRI 4" M12 Packaging unit 5 pc Thread - M M12 Clamping range - D 108 - 114 mm ¥412.50
4.0 372048 Pipe ring stainless MP-MRI 101,6 M12 Packaging unit 5 pc Thread - M M12 Clamping range - D 97 - 103 mm ¥265.00
5.0 372045 Pipe ring stainless MP-MRI 2 1/2" M10 Packaging unit 10 pc Thread - M M10 Clamping range - D 70 - 77 mm ¥327.50
6.0 372047 Pipe ring stainless MP-MRI 3" M10 Packaging unit 10 pc Thread - M M10 Clamping range - D 82 - 90 mm ¥350.00
7.0 372053 Pipe ring stainless MP-MRI 5" M16 Packaging unit 10 pc Thread - M M16 Clamping range - D 137 - 142 mm ¥460.00
8.0 372054 Pipe ring stainless MP-MRI 159 M16 Packaging unit 10 pc Thread - M M16 Clamping range - D 156 - 162 mm ¥517.50
注:本公司对上述参数保有最终解释权,如若变动,恕不通知。
MP-MRI NEW MP-MRI NEW Material composition: Stainless steel, 1.4571/1.4404 (A4) - EN 10088, AISI 316Ti / AISI 316L Temperature resistance: -50-120 °C Insulation material: EPDM rubber Features & Applications Features Pipe ring with passive fire prevention as per DIN 4102, part 2 Solid connection boss, welded all round Greater stiffness from profiled pipe ring steel band Pipe ring with verified fire resistance as per DIN 4102, part 2 Increased rigidity due to profiled clamping band Applications Heavy-duty pipe installations Heating and industry Food industry (except production) Water treatment Fastening medium-diameter pipes (68 mm to 219 mm) in corrosive environments For approval or certificate information, please see individual items.

Technical Data

30054_S19_S20_S21_APC_fv600
30054_S20_S21_APC_fv600
30054_S21_APC_fv600
30054_S19_APC_fv600
30054_S19_S20_APC_fv600
Material composition
Stainless steel, 1.4571/1.4404 (A4) - EN 10088, AISI 316Ti / AISI 316L
Temperature resistance
-50 - 120 °C
Insulation material
EPDM rubber
Hardness insulation material
50° ±5° Shore A
Clamping screw
M8
Tightening torque
3 Nm
Noise reduction
18 dB (A)
Approvals
Fire class B2
