MP-L-IM8/M10

已选总价:￥0.00
已选数量:0件

所有费用均已包含增值税，不含运费。运费详情请参阅运费指导书。

产品详情与编号

序号	产品编号	名称	Packaging unit	Thread - M	Clamping range - D	售价
	全部	全部	全部	全部	全部
1.0	2172930	Pipe clamp MP-L-I 143-156 M8/M10	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 143 - 156 mm	￥32.10
2.0	2172929	Pipe clamp MP-L-I 129-142 M8/M10	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 129 - 142 mm	￥31.50
3.0	2172925	Pipe clamp MP-L-I 83-92 M8/M10	Packaging unit 25 pc	Thread - M M8. M10	Clamping range - D 83 - 92 mm	￥23.00
4.0	2172931	Pipe clamp MP-L-I 157-170 M8/M10	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 157 - 170 mm	￥32.90
5.0	2172928	Pipe clamp MP-L-I 115-128 M8/M10	Packaging unit 10 pc	Thread - M M8. M10	Clamping range - D 115 - 128 mm	￥30.90
6.0	2172815	Pipe clamp MP-L-I 10-14 M8/M10	Packaging unit 50 pc	Thread - M M8. M10	Clamping range - D 10 - 14 mm	￥7.30
7.0	2172922	Pipe clamp MP-L-I 54-63 M8/M10	Packaging unit 50 pc	Thread - M M8. M10	Clamping range - D 54 - 63 mm	￥14.60
8.0	2172817	Pipe clamp MP-L-I 20-26 M8/M10	Packaging unit 50 pc	Thread - M M8. M10	Clamping range - D 20 - 26 mm	￥10.30
9.0	2172927	Pipe clamp MP-L-I 104-114 M8/M10	Packaging unit 25 pc	Thread - M M8. M10	Clamping range - D 104 - 114 mm	￥24.80
10.0	2172926	Pipe clamp MP-L-I 93-103 M8/M10	Packaging unit 25 pc	Thread - M M8. M10	Clamping range - D 93 - 103 mm	￥24.10
11.0	2172816	Pipe clamp MP-L-I 15-20 M8/M10	Packaging unit 50 pc	Thread - M M8. M10	Clamping range - D 15 - 20 mm	￥9.90
12.0	2172818	Pipe clamp MP-L-I 26-32 M8/M10	Packaging unit 50 pc	Thread - M M8. M10	Clamping range - D 26 - 32 mm	￥10.80
13.0	2172924	Pipe clamp MP-L-I 73-82 M8/M10	Packaging unit 25 pc	Thread - M M8. M10	Clamping range - D 73 - 82 mm	￥22.50
14.0	2172920	Pipe clamp MP-L-I 38-45 M8/M10	Packaging unit 50 pc	Thread - M M8. M10	Clamping range - D 38 - 45 mm	￥12.60
15.0	2172921	Pipe clamp MP-L-I 45-53 M8/M10	Packaging unit 50 pc	Thread - M M8. M10	Clamping range - D 45 - 53 mm	￥13.50
16.0	2172923	Pipe clamp MP-L-I 63-72 M8/M10	Packaging unit 25 pc	Thread - M M8. M10	Clamping range - D 63 - 72 mm	￥20.70
17.0	2172819	Pipe clamp MP-L-I 32-38 M8/M10	Packaging unit 50 pc	Thread - M M8. M10	Clamping range - D 32 - 38 mm	￥11.30

注：本公司对上述参数保有最终解释权，如若变动，恕不通知。

MP-L-I M8/M10 NEW MP-L-I M8/M10 NEW Thread - M: M8, M10 Material composition: DC01 - DIN EN 10130 Surface finish: Galvanized Features & Applications Features Secured hinge with wide, infinitely adjustable opening angle Clamping range without gaps across the entire pipe clamp series One-screw safety flap closure – easy single-handed closing and re-opening Unique safety flap closure mechanism prevents unintentional re-opening Significant installation time savings compared to two-screw pipe clamps Applications Light-duty pipe installations up to 6" Fastening fresh water, waste water and heating pipes in residential and industrial buildings Suitable for ceiling, floor and wall applications Pipe clamp for use in dry interiors For approval or certificate information, please see individual items.

Technical Data

PDF , English [ 917.6 kB ]

For more documents see the Documents section

Thread - M: M8, M10
Material composition: DC01 - DIN EN 10130
Surface finish: Galvanized
Insulation material: EPDM rubber
Hardness insulation material: 60° ±5° Shore A
Clamping screw: M5
Tightening torque: 2 Nm
Noise reduction: 18.5 dB (A)
Approvals: RAL-Test report MP-L-I

Documents

Approval document
- PDF RAL-GZ 655-B Pipe ring MP-L-Ir, German, [ 284.3 kB ]
Technical information
- PDF , English, [ 917.6 kB ]
Test Report
