该软管使用的材料及生产工业保证了软管高品质及喷涂软管严格的安全要求。软管满足TBbF 13/12 规范以及最终用户特殊的要求。软管PA内衬可以输送各种极性和芳香烃溶剂,涂料,油漆,胶粘剂及油类。更多涂料,油漆,清洁剂和溶剂的信息可应要求提供。
工作压力:25巴
爆破压力:75巴
温度范围:-25℃~+80℃
内衬 :黑色光滑耐磨PA内衬
外胶 :灰色NBR外胶层,耐臭氧,耐气候及UV
加强层:合成纤维
抗静电:R<10 6Ω
软管外侧标识:"Continental ContiTech FARBSPRITZ / PAINT SPRAY PA DN 9 PN 25 BAR / 363 PSI R < 106Ω Made in Germany" 轴向标记于灰色表面
Marking:“Continental ContiTech FARBSPRITZ / PAINT SPRAY PA DN 9 PN 25 BAR /363 PSI R < 106 Ω Typ M Made in Germany” on grey cover
The very high requirements, necessary for safe and reliable spray painting hoses, are achieved by using the right type of materials and well tested construction and production technologies. Relevant specifications (e.g.TRbF 131/2) as well as the specific requirements set up by the end users qualify the high standard of this product. The hose with PA lining can be used for conveying polar and aromatic solvents, paints, lacquers, glue and oils. The CONTI® Paint spray hose PA is an example of high quality and safety thus offering a maximum of economy. Further information concerning resistance to paints, lacquers, cleaning agents and solvents is available on request.
Black, non-porous, smooth and high abrasion resistant PA lining
Reinforcements: synthetic fibres
Grey NBR-cover, resistant to ozone, weather and UV
Working pressure up to 25 bar / 363 psi
Temperature range from –25°C up to +80°C / –13°F up to +176°F
Length independently electrically conductive, R < 10 6 Ω Type M,
内径毫米 |
壁厚毫米 |
外径毫米 |
公称压力 巴/20°C |
重量 千克/米 |
长度 米 |
产品编号 |
6 |
2.5 |
11 |
25 |
0.086 |
40 |
0117 151301 |
8 |
3.0 |
14 |
25 |
0.140 |
40 |
0117 151302 |
9 |
3.5 |
16 |
25 |
0.184 |
40 |
0117 151303 |
10 |
4.0 |
18 |
25 |
0.243 |
40 |
0117 151304 |
13 |
3.5 |
20 |
25 |
0.240 |
40 |
0117 151305 |
