TRIX® 通用燃气管适用于输送任何可燃气体，包括DIN 51622标准液态燃气，丙烷/丁烷，天然气，DMF，MPS及LPG。软管符合最新的DIN EN ISO 3821 标准，提供最高的安全保障。软管非常柔软，耐用，耐臭氧及耐气候，表面光滑防尘。优秀的软管品质使其数十年广泛应用于各工程公司，铸造厂，船厂，钢铁厂，汽车厂及地下隧道施工等行业。
工作压力：20巴
爆破压力：60巴
温度范围：-25℃~+60℃
内衬 ：黑色光滑NBR内衬
外胶 ：橙色光滑NBR外胶，耐臭氧，耐气候，UV及耐磨损，DN32以上布纹外胶层
加强层：合成纤维
至DN20不含任何脱芯剂，不含任何有害喷涂物质
内衬抗静电，R＜10 6Ω/m
符合 DIN EN ISO 3821要求
软管外侧标识："Continental ContiTech TRIX® ALLBRENNGAS DN 9 DIN EN ISO 3821 2MPa (20 BAR / 290 PSI) Made in Germany" 轴向标记于橙红色表面
Marking:“Continental ContiTech TRIX® ALLBRENNGAS DN 9 DIN EN ISO 3821 2MPa (20 BAR / 290 PSI) Made in Germany” on red-orange cover
The TRIX® Universal fuel gas hose is designed for the transport of all kinds of gases as well as liquid gases according to DIN 51622, propane/butane,natural gas, DMF, MPS and LPG. It meets the latest regulations of the DIN EN ISO 3821 standard and thus offers the highest possible safety. The hose is extremely robust, flexible, resistant to ozone and weather and has a smooth,dirt-proof cover. The excellent quality is the reason, why this hose is most popular and is being used for decades in installation and heating system companies,foundries, shipyards, for the construction of bridges, in the steel and car body construction, over- and underground workings, in welding shops and at manufacturers of welding apparatus.
Black, non-porous and smooth NBR lining
Reinforcements: synthetic fibres
Red-orange, smooth NBR-cover, resistant to ozone, weather, UV and abrasion, from DN 32 upward fabric patterned
Working pressure up to 20 bar / 290 psi
Temperature range from -40°C up to +60°C / -40°F up to +140°F
Highly flexible, robust
Non-buckling, dimensionally stable
Up to DN 20 release agent- and fat-free, free from any product harmful to lacquer
Lining electrically conductive, R < 106 Ω/m
According to DIN EN ISO 3821
| 内径毫米 |
壁厚毫米 |
外径毫米 |
公称压力 巴/20°C |
重量 千克/米 |
长度 米 |
产品编号 |
| 6.3 |
3.5 |
13 |
20 |
0.170 |
40 |
0119 111901 |
| 9 |
3.5 |
15.6 |
20 |
0.210 |
40 |
0119 111902 |
| 11 |
3.8 |
17.6 |
20 |
0.280 |
40 |
0119 111903 |
| 12.5 |
4.5 |
21 |
20 |
0.370 |
40 |
0119 111904 |
| 16 |
4.5 |
25 |
20 |
0.430 |
40 |
0119 111905 |
| 20 |
5.0 |
29 |
20 |
0.590 |
40 |
0119 111906 |
| 32 |
5.5 |
36 |
20 |
0.950 |
40 |
0119 111907 |
