BLAUDIECK® LGD是一款高品质，价格合理的软管。卫生级光滑，无孔内衬对气味没有任何影响，适用于各种食品饮料行业。软管与常用清洗和消毒剂相容，可以用常规方法清洗或者用CIP系统清洗。内衬及外胶均耐油脂。通过我们专用的扣压接头系统及橡胶保护环构成了完美的软管总成。
工作压力：16巴
爆破压力：48巴
温度范围：-30℃~+80℃，最高可达+90℃（20分钟）
内衬 ：白色光滑NBR内衬，对气味没有任何影响
外胶 ：蓝色布纹NBR外胶，耐臭氧，耐气候，UV及耐磨损
加强层：合成纤维
符合：EG 1935/2004 和 EG 2023/2006要求
符合：BfR XXI cat. 2 和 FDA (21 CFR 177.2600)认证
软管外侧标识：2 条白色条纹及"Continental ContiTech BLAUDIECK® FDA glass/fork symbol BfR EG 1935/2004 2023/2006 Made in Germany" 螺旋标记于蓝色表面。
Marking:2 white stripes on blue cover “Continental ContiTech BLAUDIECK® FDA glass/fork symbol BfR EG 1935/2004 2023/2006 Made in Germany”spirally applied
The BLAUDIECK® LGD-hose offers high quality at a reasonable price.The hygienically smooth, non-porous lining is absolutely neutral to taste and odour and thus suitable for various applications in the beverage and foodstuffs industry. It is resistant to commonly used cleaning and disinfecting products and can easily be cleaned conventionally or by CIP installations. Both, lining and cover are resistant to oil and fats. Together with our swaged coupling systems and rubber protection rings it becomes the ideal hose assembly!
White, non-porous and smooth NBR lining, absolutely neutral to taste and odour
Reinforcements: synthetic fibres
Blue, fabric patterned NBR-cover, resistant to ozone, weather, UV and abrasion
Working pressure up to 16 bar / 232 psi
Temperature range from -30°C up to +80°C / -22°F up to +176°F (+90°C/ +194°F max. 20 minutes)
Can be steamed up to +110°C / +230°F (+130°C / +266°F max. 20 minutes)
Lining and cover resistant to oil and fats
Meets the requirements of EG 1935/2004 and EG 2023/2006
Meets the recommendation XXI cat. 2 of BfR and FDA (21 CFR 177.2600)
| 内径毫米 |
壁厚毫米 |
外径毫米 |
公称压力 巴/20°C |
重量 千克/米 |
长度 米 |
产品编号 |
| 13 |
4.0 |
21 |
16 |
0.280 |
40 |
0120 111601 |
| 16 |
4.0 |
24 |
16 |
0.320 |
40 |
0120 111602 |
| 19 |
5.0 |
29 |
16 |
0.500 |
40 |
0120 111603 |
| 25 |
6.0 |
37 |
16 |
0.800 |
40 |
0120 111604 |
| 32 |
8.0 |
48 |
16 |
1.400 |
40 |
0120 111605 |
| 38 |
9.0 |
56 |
16 |
1.900 |
40 |
0120 111606 |
| 40 |
9.0 |
58 |
16 |
2.700 |
40 |
0120 111607 |
