COLLECTOR® FLEX 是COLLECTOR®的升级版，即使在低温下，螺旋塑料线增强层的超柔性，使得软管显示出优异的操控性。其白色内衬由天然橡胶制成，对气味没有任何影响，与原奶和常规清洁剂相容。NR外胶层耐磨损，抗UV及臭氧。
工作压力：6巴
爆破压力：18巴
温度范围：-40℃~+70℃，最高+90℃（20分钟内）
内衬 ：白色光滑NR内衬，无气味
外胶 ：蓝色布纹NR外胶，耐臭氧，耐气候，UV及耐磨损
加强层：合成纤维及螺旋塑料线
符合EG 1935/2004 和 EG 2023/2006要求
符合BfR XXI cat. 2 和 FDA (21 CFR 177.2600) 认证
软管外侧标识：2 条平行红色及 "Continental ContiTech COLLECTOR® FLEX FDA glass/fork symbol BfR EG 1935/2004 2023/2006 Made in Germany" 螺旋标记于蓝色表面
Marking:2 parallel, spirally applied red stripes, interrupted by the words “Continental ContiTech COLLECTOR® FLEX FDA glass/fork symbol BfR EG 1935/2004 2023/2006 Made in Germany” on blue cover
COLLECTOR® FLEX is a further development of the established COLLECTOR® quality. Thanks to the flexibiliy of the new integrated plastic helix, the hose shows an excellent handling, even at low temperatures. Its white lining made from natural rubber is absolutely neutral to taste and odour, resistant to raw milk as well as to commonly used cleaning products.The NR cover is resistant to abrasion, UV and ozone.
White, homogeneous, smooth, NR-lining, absolutely neutral to taste and odour
Reinforcements: synthetic fibres
With plastic helix
Blue, fabric patterned NR-cover, resistant to ozone, weather, UV and abrasion
Working pressure up to 6 bar / 87 psi
Temperature range from –40°C up to +70°C / –40°F up to +158°F(+90°C / +194°F max. 20 minutes)
Can be steamed up to +130°C / +266°F (max. 20 minutes)
Flexible and lightweight
Meets the requirements of EG 1935/2004 and EG 2023/2006
Meets the recommendation XXI cat. 2 of BfR and FDA (21 CFR 177.2600)
| 内径毫米 |
壁厚毫米 |
外径毫米 |
公称压力 巴/20°C |
重量 千克/米 |
长度 米 |
产品编号 |
| 40 |
6.5 |
53 |
6 |
1.290 |
40 |
0120 121501 |
| 45 |
6.5 |
58 |
6 |
1.440 |
40 |
0120 121502 |
| 50 |
6.5 |
63 |
6 |
1.620 |
40 |
0120 121503 |
| 53 |
6.5 |
66 |
6 |
1.700 |
40 |
0120 121504 |
| 55 |
6.5 |
68 |
6 |
1.760 |
40 |
0120 121505 |
| 63 |
6.5 |
76 |
6 |
1.870 |
40 |
0120 121506 |
| 70 |
7.0 |
84 |
6 |
2.270 |
40 |
0120 121507 |
| 75 |
7.5 |
90 |
6 |
2.400 |
40 |
0120 121508 |
| 100 |
8.0 |
116 |
6 |
3.240 |
40 |
0120 121509 |
