冷却水管
基本参数
英文名称
Inducord/Glasfiber
工作压力
20 bar
爆破压力
60 bar
温度范围
+100℃~+450℃
内衬
白色绝缘EPDM
外胶
白色光滑抗高温玻璃纤维
加强层
纺织编织加强层
  • 已选总价:¥0.00
  • 已选数量:0
所有费用均已包含增值税,不含运费。运费详情请参阅运费指导书。
产品详情与编号
序号 产品编号 名称 工作压力 温度范围 内径(mm) 外径(mm) 长度(m) 售价 订购数量
  全部
全部
全部
全部
全部
全部
全部

0.0 3042025039 冷却水隔热管 20bar 100℃~+450℃ 25 39 40 ¥286.00
0.0 3042050000 冷却水隔热管 20bar 100℃~+450℃ 50 70 40 ¥542.00
0.0 3042045062 冷却水隔热管 20bar 100℃~+450℃ 45 62 40 ¥466.00
0.0 3042038058 冷却水隔热管 20bar 100℃~+450℃ 38 58 40 ¥450.00
0.0 3042076096 冷却水隔热管 20bar 100℃~+450℃ 76 96 40 ¥743.00
0.0 3042019031 冷却水隔热管 20bar 100℃~+450℃ 19 31 40 ¥247.00
0.0 3042032048 冷却水隔热管 20bar 100℃~+450℃ 32 48 40 ¥355.00
0.0 3042042000 冷却水隔热管 20bar 100℃~+450℃ 42 60 40 ¥448.00
0.0 3042040057 冷却水隔热管 20bar 100℃~+450℃ 40 57 40 ¥410.00
0.0 3042013025 冷却水隔热管 20bar 100℃~+450℃ 13 25 40 ¥230.00
注:本公司对上述参数保有最终解释权,如若变动,恕不通知。
玻璃纤维材质、隔热性能优良;适用于熔炼厂、钢铁厂、玻璃厂、铸造厂等高温工作环境
工作压力:20巴
爆破压力:60巴
温度范围:-30℃~+80℃
温度范围:水温100℃至温度+450℃
内衬 :白色绝缘EPDM
外胶 :白色光滑抗高温玻璃纤维
加强层 :纺织编织加强层

Waterhose with heat-insulating properties, for melting furnaces, steel works, glassworks, foundries and sites dealing with high temperatures.
Working pressure : 20 bar
Burst pressure : 60 bar
Temperature range : +100°C Watertemperature till +450°C heatradiation
Tube : EPDM, white, elecrically isolating
Cover : Glassfiber plies, white smooth
Reinforcements : textile plies


内径毫米 壁厚毫米 外径毫米 长度 米 产品编号
13 6 25 40 3042013025
19 6 31 40 3042019031
25 7 39 40 3042025039
32 8 48 40 3042032048
38 10 58 40 3042038058
40 8.5 57 40 3042040057
42 9 60 40 3042042000
45 8.5 62 40 3042045062
50 10 70 40 3042050000
76 10 96 40 3042076096
